نموذج: NP1550nm NP1064 NP808nm
The file is encrypted. Please fill in the following information to continue accessing it
| Parameter | Specification |
| Center Wavelengths (CWL) | 08nm, 1064nm, 1550nm (Custom IR CWLs available 700nm - 2500nm) |
| Bandwidth (FWHM) | 10nm ± 2nm (Tighter tolerances available upon request) |
| Peak Transmission | >90% (Typically >93%) |
| Out-of-Band Blocking | OD4 (Optical Density 4) Standard; OD6 for Raman/Laser applications |
| Substrate Material | IR Grade Fused Silica or N-BK7 |
| Surface Quality | 40-20 S/D (Scratch-Dig) |
| Samples | Available For Reuest Samples size |
| Coating Type | Hard Dielectric Sputtered Coatings |
